100L Chocolate Conche Refiner 5.5kW 380V for Chocolate Production
-
Highlight
100L chocolate conche refiner
,5.5kW chocolate conche machine
,380V chocolate production equipment
-
Voltage380V 50Hz 3Phase Or Customized
-
Power5.5 KW
-
Dimension1200*1150*1050mm
-
Weight1050 KG
-
Capacity100L
-
MaterialCarbon Steel Or Stainless Steel
-
Grinding Time8-10h
-
Grinding Fineness20~25micron
-
Main Axle Speed48 Rpm
-
Main Motor Power5.5 KW
-
Electrical Heating Power2.5 KW
-
Blade MaterialManganese Steel
-
Batch Size100kg/batch
-
Temperature ControlAutomatic
-
Lining Bar MaterialManganese Steel
-
Place of OriginJiangsu, China
-
CertificationISO CE
-
Minimum Order Quantity1
-
Price$5,600
100L Chocolate Conche Refiner 5.5kW 380V for Chocolate Production
Universal Chocolate Conche Refiner Melanger Conche (20L, 40L, 100L, 500L)
Product Description
Application:
- Ideal production solution for chocolate shops and labs with three functions: raw material mixing, chocolate mass grinding & refining, and conching
- Suitable for making chocolate mass and various fillings for chocolate products
Technical Parameters
| Model/Project | 20L | 100L | 500L | 1000L | 1500L | 2000L | 3000L |
|---|---|---|---|---|---|---|---|
| Maximum capacity (L) | 20 | 100 | 500 | 1000 | 1500 | 2000 | 3000 |
| Grinding Fineness (micron) | 20-25 | 20-25 | 20-25 | 20-25 | 20-25 | 20-25 | 20-25 |
| Main Axle Rotating Speed (rpm) | 93 | 48 | 33 | 35 | 35 | 35 | 35 |
| Grinding time (h) | 8-10 | 12-16 | 16-22 | 16-22 | 16-22 | 16-22 | 16-22 |
| Main motor power (kw) | 1.5 | 5.5 | 15 | 22 | 30 | 37 | 45 |
| Electrical heating power (kw) | 0.6 | 2.5 | 5 | 2×2 | 6 | 3×2 | 12 |
| Weight (kg) | 295 | 1050 | 2572 | 3050 | 4850 | 5350 | 7500 |
| Outside dimensions (mm) | 920×600×1110 | 1200×1150×1050 | 2465×1146×1312 | 2627×1280×1520 | 2918×1650×1920 | 3040×1912×1920 | 3450×2016×2280 |
Product Images
Detail Images
Key Features
- Manganese steel blades and lining bars with extended lifespan, processed and strengthened by special heating system
- Operator-friendly design:
- 100kg batch capacity for easy raw material loading
- Equipped with solenoid valve and automatic temperature control system
- Compact 20L model ideal for limited space requirements
Processing Images
Workshop
Our 100L chocolate conche refiner is highly popular among chocolate shops and labs. We maintain a production capacity of 50 units per month. With in-house manufacturing of nearly all components (except motors and electrical parts), we ensure strict quality control throughout the production process.
Company Profile
Suzhou Harmo Food Machinery, based in Suzhou, China, is a professional chocolate machine manufacturer with complete production facilities. We maintain control over quality from raw materials to finished products by manufacturing nearly all components in-house (excluding motors and electrical parts).
Our chocolate machines are exported worldwide, including to USA, Canada, South America, Middle East, North Africa, Eastern Europe, and Asia. Our extensive manufacturing experience allows us to provide optimal chocolate equipment and production processes for global customers.
Quality is our core value, and service is our principle. We prioritize quality over price and strive to respond promptly to all customer inquiries. Our mission is to learn from customers, work with customers, and provide reliable chocolate equipment with proper production solutions.
Certifications
Product Packaging
Frequently Asked Questions
Q1: Can you provide invitation letter for customers and arrange pick-up at the airport if they want to visit your factory?
A1: Yes. We can provide invitation letter and arrange our driver or sales to pick up customers at Shanghai airport or train station.
Q2: What is your warranty period?
A2: Our warranty is 12 months or 14 months after shipment.
Q3: Will you test the machine after manufacturing?
A3: Yes. All our machines will be tested with oil or raw materials before shipping by our technician.
Q4: Can you supply machines which conform to European Standard or American standard?
A4: Yes. We exported our machines to USA, Canada, Hungary and Belgium, etc.
Q5: What can we do if goods were damaged during shipping?
A5: Firstly, We will pack goods and fix them well in our factory. Secondly, If goods were damaged during sea shipping, we will deliver parts to you try our best. So you can replace damaged parts and run machines ASAP.
Q6: Can you arrange loading in your factory if customer bought products from different suppliers?
A6: Yes,we can load all products in our factory and ship all goods by one or two containers.
Q7: Do you provide installation and commissioning service?
A7: Yes, we can deliver our technician to do installation and commissioning in customers' factory. After installation, our technician will provide training for stuff in the factory.
Q8: Do you provide recipe if customer buys whole production line?
A8: Yes, we can provide a basic recipe, then customer can adjust the recipe according to customer's local market demand.
Q9: Do you provide instruction manual and maintenance schedule?
A9: Yes. We will provide detailed instruction manual and maintenance schedule before shipping.
Q10: Can you make customized machine?
A10: Yes, we can customize the machine according to the final product. Also we can provide turnkey project for our customers.
