40L Chocolate Conche Machine 5.5kw Carbon Steel Continuous Type

MOQ:	1
Price:	US$3,800

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu, China

Voltage:

Customized

Power:

5.5kw

Dimension:

1200*1150*1050 Mm

Weight:

1050 KG

Capacity:

40L

Material:

Carbon Steel

Main Motor Power:

5.5 Kw

Electrical Heating Power:

2.5 Kw

Grinding Fineness:

20-25 Micron

Main Axle Speed:

48 Rpm

Grinding Time:

12-16 H

Color:

Silver

Core Components:

Bearing, Motor, Gear

Lining Bars Material:

Manganese Steel

Blades Material:

Manganese Steel

Highlight:

40L chocolate conche machine

carbon steel conche machine

continuous chocolate conche machine

Product Description

Premier Chocolate Refiner Conche (20L, 40L, 100L)

Key Features

Continuous type operation for efficient chocolate production
Precision fine grinding of chocolate mass (20-25 micron fineness)
Main equipment in chocolate production lines
Customizable voltage options
1-year warranty on core components (bearing, motor, gear)

Technical Specifications

Attribute	Value
Condition	New
Capacity	40L (20L-3000L available)
Main Motor Power	5.5 kW
Electrical Heating Power	2.5 kW
Dimensions (L×W×H)	1200 × 1150 × 1050 mm
Weight	1050 kg
Material	Carbon steel
Color	Silver
Warranty	1 Year

Product Gallery

Model Specifications

Model	20	100	500	1000	1500	2000	3000
Capacity	20L	100L	500L	1000L	1500L	2000L	3000L
Grinding Fineness (micron)	20-25	20-25	20-25	20-25	20-25	20-25	20-25
Main Motor Power (kW)	1.5	5.5	15	22	30	37	45
Weight (kg)	295	1050	2572	3050	4850	5350	7500

Frequently Asked Questions

Q: What is your warranty period?

A: Our warranty is 12 months or 14 months after shipment.

Q: Will you test the machine after manufacturing?

A: Yes. All our machines will be tested with oil or raw materials before shipping by our technician.

Q: Can you supply machines which conform to European Standard or American standard?

A: Yes. We exported our machines to USA, Canada, Hungary and Belgium, etc.

Q: Do you provide recipe if customer buys conche refiner?

A: Yes, we can provide a basic recipe, then customer can adjust the recipe according to customer's local market demand.
